A-A79W9 — Electrical One-Line Distribution Diagram

Electrical · A-A79W9

Electrical One-Line Distribution Diagram

About this detail

An electrical distribution riser diagram showing power flow from main switchboard feeds MSB-1, MSB-2, and MSB-3 to panels Y1, Y2, X, and V. Step-down transformers XFMR TB, XFMR TC, and XFMR TD convert 480V to 120/208V with capacities of 75kVA and 45kVA in 3-phase 4-wire configurations. Secondary feeders run from the transformers to downstream distribution panels B, C1, C2, and D.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
