A dual egress door frame installs within a rated partition assembly while maintaining wall rating continuity. A swing-clear hinge allows the scheduled door to open fully without obstructing the clear corridor width. Dimensional clearances include a two and five-eighths inch clear opening zone and a two-inch setback, with half-inch drywall returns on both sides of the jamb.
CLEAR CORRIDOR OPENING CLR 2 5/8" SIZE TO FIT PARTITION SCHEDULED DOOR IN OPEN POSITION SWING-CLEAR HINGE WALL RATING CONTINUITY 1/2" 2" 1/2"
