An existing concrete tilt wall has its architectural wythe and insulation sawcut to accommodate a structural steel framing goalpost. A three-inch by three-inch by one-eighth-inch closure angle is anchored at three feet on center and painted. A steel angle bracket detailed per structural requirements secures the framing. A concrete curb sits adjacent to the connection assembly.
5 2-x 2'-0" 1'-4 1/2" 1'-0" V.I.F. 1'-1 1/2" GOALPOSTS TYP. SCHEDULED OPENING; COORD WITH DEMOLITION PLANS AND STRUCTURAL CONCRETE CURB TYP. EXISTING CONCRETE TILT WALL 8" L3X3X1/8" CLOSURE; PAINT ANCHOR 3'-0" O.C STEEL ANGLE BRACKET PER STRUCTURAL STRUCTURAL STEEL FRAMING 3 A501 SAWCUT EXISTING ARCHITECTURAL WYTHE OF TILT PANEL AND INSULATION TO ACCOMMODATE STEEL BRACE 1" 2'-0" SAWCUT EXISTING ARCHITECTURAL WYTHE OF TILT PANEL
