This horizontal section details the intersection of a perforated metal sunscreen with a wood-framed wall assembly. The wall features wood siding aligned to the edge of the wood soffit below, with a steel sunscreen support finished per PT-10. The sunscreen assembly terminates adjacent to a flat pan standing seam metal panel with a ninety-degree corner, finished to match the typical standing seam panels. The wall cavity includes insulation and is framed with an eight-and-a-half-inch and one-foot-one-eighth-inch spacing. The assembly integrates with the roof fascia line below and accommodates raised metal building signage.
