A stainless steel grab bar is secured to a Type 1 backing plate concealed within the partition assembly using three quarter-inch by two and a half inch diameter stainless steel Phillips round head machine screws at each flange. The partition features a porcelain tile wall finish over a backing specified on the architectural plans. The installation maintains a typical one and a half inch clearance between the grab bar and the finished wall surface.
SEE PLAN FOR PARTITION TYPE PORCELAIN TILE, W.O. TYPE 1 BACKING PLATE STAINLESS STEEL GRAB BAR SECURE TO BACKING PLATE W/ 3- 1/4" X 2 1/2" Ø STAINLESS STEEL PHILIP ROUND HEAD MACHINE SCREWS @ EACH FLANGE, TYP. CLR. 1 1/2" one inch = one foot 2 0 6" 6" 0 2 three quarters inch = one foot 3 TYP. GRAB BAR DETAIL
