A higher priority partition passes continuously through the junction while two lower priority partitions abut against it from opposite sides. Jamb studs are installed as required within the wall framing. A hollow metal frame wraps the intersection at the designated door location.
DOOR LOCATION JAMB STUDS AS REQUIRED HOLLOW METAL FRAME LOWER PRIORITY PARTITION HIGHER PRIORITY PARTITION INTERSECTION AT CROSS
