A concrete roadway curb is finished with OSHA safety red paint to designate a fire lane. Three-inch high white lettering reading FIRE LANE NO PARKING is applied along the painted surface at thirty inches on center or portion thereof. The adjacent roadway construction is coordinated with civil engineering drawings.
OSHA SAFETY RED PAINT ROAD WAY - SEE CIVIL 3-INCH HIGH WHITE LETTERING @ 30' O.C. OR PORTION THEREOF. FIRE LANE NO PARKING STAMP # 11/16/2022 12/08/2022
