A furred partition assembly consists of steel studs finished with gypsum board on one side. The assembly has a total thickness of two and one-quarter inches, utilizing a one and five-eighths inch steel stud and a five-eighths inch gypsum board layer. Head and base details reference sheets for anchoring and connection conditions.
5/8" 1 5/8" STC RATING : FIRE RATING : LIMITING HEIGHT : HEAD DETAIL : BASE DETAIL : F-AJ FURRED PARTITION N/A N/A N/A 7 / A8.01 1 / A8.01 09 2900 GYPSUM BOARD 09 2216 STEEL STUD 2 1/4"
