An exterior cement plaster wall assembly incorporates a two-piece metal expansion joint with insulation. Rigid insulation is installed behind a cement plaster finish over metal lath secured with wire ties. A Brand X Diamond Furr DFXS-1375 metal expansion joint accommodates movement within the plaster layer.
METAL LATH WIRE TIRE 2-PIECE MTL. EXPANSION JOINT: BRAND X DIAMOND FURR DFXS-1375 CEMENT PLASTER RIGID INSULATION EXPANSION JOINT W/ INSULATION
