Architectural · A-9TC5N

Plan Detail Room 105

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Gypsum / Drywall

Elements

Floors / Slabs Insulation Partitions Walls

Text on the drawing

5 ACOUSTIC WALL ASSEMBLY RE: FLOOR PLANS PLUMBING WALL TILE (WHERE OCCURS) A6G A6G
