A floating counter is constructed from plastic laminate wrapped plywood with a perimeter stud framing layout typical. The assembly rests on a three-quarter inch thick vertical plywood support wrapped with plastic laminate on each side. A storefront mullion is positioned beyond the counter assembly at a maximum height of thirty-four inches from the finished floor.
MAX 34" 4" 30" STOREFRONT MULLION BEYOND PLAM WRAPPED PLYWOOD (WV-1) 3/4" PLYWOOD VERITCAL SUPPORT WITH PLAM (WV-1) EACH SIDE, SEE INTERIOR ELEVATIONS STUD AROUND PERIMETER, TYP 2' - 0"
