Architectural · A-9Q27Y

Cable Barrier Post at Concrete Spandrel and Column

Materials

Elements

About this detail

A cable barrier post is mounted adjacent to a concrete spandrel beam finished with a textured coating on the front, top, and inside faces. The support structure includes a concrete column featuring three-quarter-inch chamfers on all corners and three sides finished with textured coating. The column line falls within the spandrel or upturn beam where applicable. The entire cable railing and barrier post assembly is painted to match the adjacent column, spandrel, and upturn beam.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
