This assembly consists of a vertical blade louver frame mounted atop a metal sill pan, which is shimmed as required to ensure proper drainage. The louver frame is secured to the substrate and sealed at the interior with sealant and a backer rod. An insect screen is integrated into the louver system. The sill pan extends outward to form a drip edge, and the entire assembly is positioned to maintain a weather-tight seal at the louver base.
Text on the drawing
INTERIOR 02 A-60009 TYP SCHEDULED LOUVER FRAME SEALANT AND BACKER ROD, PROVIDE WEEPS SHIMS VERTICAL BLADE LOUVER SILL PAN, SHIM AS REQ'D FOR DRAINAGE INSECT SCREEN
