An internal cold-formed steel stud wall terminates below the roof structure utilizing a deflection track to accommodate roof movement. Fixing straps or noggings are provided for securing linings to the wall framing. A prefinished metal cover trim conceals the joint at the ceiling level. The wall assembly is finished on both sides per the interior wall schedule and is designed for zero-hour fire resistance rated internal walls, with structural elements such as DLT referenced in structural documentation.
DEFLECTION TRACK EXTERIOR INTERIOR FIXING STRAP OR NOGGINGS FOR FIXING LINGS SHEET TO WALL FRAMING PREFINISHED METAL COVER TRIM RF5 INTERIOR TYPICAL WALL ASSEMBLY, REFER TO LOCATION PLANS AND WALL SCHEDULE DETAIL IS FOR 0 HOUR FIRE RESISTANCE RATED INTERNAL WALLS DLT, REFER TO STRUCTURAL DOCUMENTATION
