The intermediate landing assembly consists of steel channel stringers supporting subframing with equal spacing dimensions. Subframing at intermediate landings is restricted from extending below the bottom of the steel channel stringer. A guard rail extension is positioned adjacent to the stair enclosure partition, with dimensions coordinated per enlarged floor plans.
REFER TO DETAIL 1/A6.06 FOR TYPICAL INFORMATION NOT SHOWN GUARD RAIL EXTENSION; REFER TO ENLARGED FLOOR PLANS FACE OF STAIR ENCLOSURE PARTITION EQ REFER TO ENLARGED PLANS EQ EQ 6" 3" SUBFRAMING AT INTERMEDIATE LANDINGS SHALL NOT EXTEND BELOW BOTTOM OF STEEL CHANNEL STRINGER, TYP. EQ
