A wood fin connects to a c-channel beam assembly backed by continuous blocking. The wood fin fastens to the blocking with connections per structural sheet S.7.02. A stud connection also ties into the assembly spaced per fin spacing per architectural detail 1/A.8.03, concealed behind the fin typically. Beam connections are detailed per structural sheet S.7.02.
