This plan detail shows the jamb and recessed pocket layout for a folding security grill. The pocket width is dimensioned at three feet three inches with contractor verification required. Inside the wall assembly, curves are radius-dimensioned at one foot six inches and ten inches, maintaining an eight-inch clear opening.
NEC 1 Servery Countertop, Refer To Floor Plan NE1.4 Below A5 AE4-31 1' - 2" 4" 1' - 2" 2 4" 2' - 4" 5/8" 5' - 2 1/8" 8 3/8" 5/8" 8" Clear R 1' - 6" R 10" 5 6 7 3 8 8" Clear Contractor to Verify 3' - 3" Pocket Width 10 AE5-01 D2 Sim. 6 1 5/8" 8 3/8" 1' - 6 3/8" 5/8"
