An exterior door header assembly transitions from a concrete wall to a hollow metal or aluminum storefront frame. Continuous sealant caulking is applied on each side of the frame head against the concrete wall. A Pemko raindrip is attached to the exterior face of the storefront frame using factory-provided number 6 by 5/8 inch Phillips pan head sheet metal screws. A painted door is installed below, finished to match the concrete panel color.
EXTERIOR SIDE INTERIOR SIDE CONCRETE WALL, SEE PLANS AND SCHEDULES DOOR, SEE PLANS AND SCHEDULES CAULK w/ CONT. SEALANT EA. SIDE PAINTED DOOR. PAINT TO MATCH CONCRETE PANEL COLOR HOLLOW METAL OR ALUMINUM STOREFRONT, PER SCHEDULE PEMKO RAINDRIP DOOR 346 C 40". FINISH TO MATCH DOOR FRAME. NO. 6 X 5/8" PHSMS, PHILLIPS (FACTORY PROVIDED) 2 1/2" 1 1/2" 5/8"
