A drift head condition at a vertical metal panel exterior wall assembly. The exterior features vertical metal cladding installed over Z-furring, with an inside closure sealed with tape mastic at the top and bottom. Water-resistive barrier laps over the wall flashing, accompanied by flexible flashing and two inches of rigid wall insulation. The interior backing consists of gypsum wall board incorporating a control joint and a structural drift joint detail.
478' - 10 1/2" METAL FLASHING INSIDE CLOSURE W/TAPE MASTIC OR SEALANT @ TOP AND BOTTOM VERTICAL METAL CLADDING WRB. LAP OVER WALL FLASHING Z-FURRING EW8 EW8 DRIFT JOINT - 4TH FL. 3/4" 2 1/2" WRB. LAP OVER WALL FLASHING 2" RIGID WALL INSULATION GWB CONTROL JOINT DRIFT JOINT PER STRUCTURAL FLEXIBLE FLASHING FLEXIBLE FLASHING WRB
