An exterior wall assembly plan detail features cold-formed metal framing on the interior side, faced with gypsum sheathing. A fluid-applied vapor permeable air and water barrier coats the exterior side of the sheathing, followed by a drainage mat and mineral wool board insulation. A continuous layer of building paper and a drainage mat sit beneath the portland cement plaster finish coat, which incorporates a V-groove architectural detail.
EXTERIOR INTERIOR 05 40 00 COLD-FORMED METAL FRAMING 06 16 43 GYPSUM SHEATHING 07 21 00 MINERAL WOOL BOARD INSULATION 07 27 26 FLUID-APPLIED VAPOR PERMEABLE AWB 07 13 00 DRAINAGE MAT 09 24 00 FINISH COAT OF PORTLAND CEMENT PLASTERING. REQUIRE A "DRAINAGE STUCCO" 09 24 00 CONTINUOUS LAYER OF BUILDING PAPER V-GROOVE REFER TO EXTERIOR ELEVATIONS FOR LOCATIONS AND SPACING 07 13 00 DRAINAGE MAT
