Elevator Mounting Heights

Elements

Stairs Floors / Slabs Roof / Floor Openings

About this detail

Elevator door jamb and adjacent wall assembly showing mounting heights and clearances for accessibility devices. The bottom call button is located at a maximum height of five feet zero inches, with tactile characters and accompanying braille positioned on both sides of the jamb. Call lanterns, emergency call stations, evacuation plans, and star of life symbols are positioned at specific heights relative to the floor landing. Reopening devices and floor landing raised characters are aligned with the elevator entrance configuration.
