This plan detail shows the connection and clearance assembly at a typical perimeter glulam column, maintaining a two-inch minimum clearance. Metal furring and batt insulation line the adjacent wall assembly. A neoprene gasket and continuous sealant joints provide weatherstripping and sealing at the column perimeter.
GRID 1'-11 1/8" 6 3/8" 1'-4 3/4" 8" 3" 2'-0 3/8" 2'-4 1/2" GRID GRID 9 1/2" 2" MIN CLR 9 1/2" MIN CLR SEE PLAN ALIGN 2" SEALANT NEOPRENE GASKET 34 A511 _____________________ SEE PLAN METAL FURRING SEALANT GLULAM 3 7/8"
