A hollow metal fully welded frame is set into a framed partition and sealed at both sides with five-eighths inch continuous non-hardening resilient sealant where the frame meets the finished opening wall. The window head includes a header assembly and an adjacent shade assembly mounted where indicated. Glass glazing is secured with a glazing stop and countersunk fasteners on the secure side only. The sill perimeter is insulated at specific interior library windows, and all hollow metal frames are primed and painted.
HOLLOW METAL FULLY WELDED FRAME; SEE WINDOW SCHEDULE B WINDOW HEAD (JAMB SIM.) 2" TYP. 5/8" CONT. NON-HARDENING RESILIENT SEALANT WHERE FRAME MEETS F.O. WALL, TYP., BOTH SIDES NOTE: ALL HM FRAMES TO BE PRIMED AND PAINTED. A WINDOW SILL GLAZING STOP W/ COUNTERSUNK FASTENER; SECURE SIDE ONLY GLAZING PER WINDOW SCHEDULE 2" TYP. 5/8" HEADER ASSEMBLY; S.S.D. PARTITION; SEE PLANS FOR LOCATIONS AND PARTITION SCHEDULE FOR ASSEMBLY SHADE ASSEMBLY WHERE OCCURS; SEE WINDOW SCHEDULE INSULATE PERIMETER OF FRAME AT THE TWO INTERIOR WINDOWS IN LIBRARY, Y-1 & Y-2
