Head or sill junction of a new window installed within an existing masonry wall assembly. The existing masonry wall supports an existing window sill beyond, with a new window anchored directly into the overhead masonry structure via threaded fasteners and shim spaces. The assembly accommodates existing wall construction conditions while integrating the new window frame.
