Installation requirements and mounting dimensions for a wall-mounted lavatory and mirror. The lavatory is positioned with a rim height between two feet five inches minimum clearance and two feet ten inches maximum to the rim. The bottom of the mirror reflective surface is located at a maximum of three feet four inches. Additional clearances include an eight inch minimum projection, a six inch maximum, and a nine inch minimum distance from the floor.
LAVATORIES ADJ TO A WALL SHALL BE MOUNTED 18" MIN. (OR GREATER AS INDICATED ON PLAN) FROM ADJ. WALL TO CENTERLINE OF FIXTURE BOT. OF MIRROR REFLECTIVE SURFACE WALL-MOUNTED LAVATORY AND MIRROR (SIDE VIEW) 8" MIN. 6" MAX. 9" MIN. 2'-5" MIN. CLR. 2'-10" MAX. TO RIM. 3'-4" MAX.
