An interior architectural painted gypsum board soffit and fascia assembly is constructed over 3-5/8-inch metal studs spaced at 16 inches on center. The framing incorporates lateral bracing as detailed on sheet A-810 and is secured with 4 No. 10 sheet metal screws at each stud. A J-moulding is taped in and painted to match the gypsum board at the cove edge, and corner beads finish the exterior drywall corners. Painted gypsum board clads the metal studs on both the vertical fascia and the horizontal soffit surfaces.
PTD GYP BOARD ON MTL STUDS @ 16" O.C. CORNER BEAD LATERAL BRACING SEE PTD GYP BOARD ON 3 5/8" MTL STUDS @ 16" O.C. - PAINT GYP BOARD IN COVE TO MATCH CEILING, TYP 'J' MOULDING - TAPED-IN AND PTD TO MATCH GYP BOARD END TRACK - SECURE TO FRAMING W/ #10 S.M.S ATT & B FLANGE, TYP. (4) #10 S.M.S, TYP EACH STUD SEE RCP 1" / 11 A-810
