Metal fabric attaches to the structural member using an intermediate attachment plate per structural engineering. An intermediate pivot link connects to the structural member with a two-inch verified offset dimension to centerline. An intermediate tube and tie-wrap assembly secures the metal fabric to the horizontal framing element per shop drawings. A dimension point aligns with the centerline per the elevations.
INTERMEDIATE ATTACHMENT PLATE PER STRUCTURAL INTERMEDIATE PIVOT LINK PER SHOP DRAWINGS METAL FABRIC STRUCTURAL MEMBER DIM POINT - SEE ELEVATIONS L C VERIFY 2" 6" INTERMEDIATE TUBE AND TIE- WRAP ASSEMBLY PER SHOP DRAWINGS FOS PIPE PENETRATION THROUGH (2) "U" FLAT BAR FRAME HALVES AT
