A structural steel connection features a three-eighths-inch gusset plate welded to a girder per plan with five-sixteenths-inch fillet welds. Framing members per plan intersect at grid line twelve and connect to the gusset plate with minimum six-inch clearances. The assembly incorporates special seismic force resisting system designation.
RAE 01 109' - 10 3/4" 12 5/16 5/16 SFRS MEMBER PER PLAN MEMBER PER PLAN GUSSET, PL 3/8" 3" 6" MIN 6" MIN 1' - 4 3/4" 3" GIRDER PER PLAN GIRDER CONNECTION
