Electrical · A-9C7N2

Typical Raceway Support Methods Detail

Elements

About this detail

These isometric details illustrate standard methods for supporting electrical raceways ranging from one-half inch to six inches in diameter from overhead structural units. A beam clamp or hanger clamp, sized as required by the supported weight, attaches directly to the structural steel member. Depending on the configuration, an all-thread rod of required size suspends a conduit hanger, or the raceway is secured directly via the clamp. A general note explicitly prohibits the use of tie wire as a component of any raceway hanger system.
