An architecturally exposed structural steel canopy beam supports glass and painted aluminum fins with variable depth construction. The tube intersections are cut and welded with all welds ground smooth. Glass supports attach to the top flange beyond, while metal straps and shims as required connect the painted aluminum fins.
5 " 1 / 2 " D E P T H V A R I E S INTERSECTION OF TUBES TO BE CUT AND WELDED ALL WELDS TO BE GROUND SMOOTH TOP FLANGE BEYOND AESS PAINTED STEEL STRUCTURE GLASS SUPPORT 4 " 4 " PAINTED ALUMINUM FIN M E T A L S T R A P T O C O N N E C T F I N S S H I M A S R E Q
