A coiling door head is framed with a structural steel tube support and enclosed with gypsum wallboard on metal stud framing. The assembly features an exposed 1/4-inch powder-coated plate secured with countersunk fasteners on centerlines, finished with a 1/2-inch by 1/2-inch reveal trim. The coiling door mechanism and hood attach adjacent to the framed structural opening per manufacturer requirements.
092900.GWB 092216.T 083323.OCD 083323.T 083323.H 3" DOOR MFR ELEVATION PER 051200.T 8X4 SEE STRUCT 051200.PL 092900.GWB 092900.AT 1/2" X 1/2" 1/4" - POWDERCOAT 061000.WS COUNTERSUNK FASTENERS ON CL 7 8
