Architectural · A-9AG46

Tactile Not an Exit Sign

Elements

About this detail

Installation and dimensional requirements for a tactile "Not An Exit" sign in accordance with local accessibility standards. The sign features uppercase sans-serif characters raised one-thirty-second of an inch with corresponding Grade 2 braille positioned below the text. Characters and background must possess a non-glare finish with distinct color contrast against the mounting wall, typically utilizing white lettering on a blue background. Specific vertical spacing dimensions govern character height ranges, baseline offsets, and braille positioning tolerances.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
