The mounting configuration for circular base-mounted equipment secured to a concrete support. The equipment unit features typical anchor bolts positioned near the top and bottom flanges. The center of gravity is designated at height Z from the base within the overall equipment height H. Expansion anchors or cast-in-place anchor bolts secure the base to the underlying structural concrete.
