Grab bars are positioned at a typical height of two feet ten inches to the centerline above the finished floor. Side wall toilet grab bars maintain a fifty-four inch minimum length with specific clearance dimensions from adjacent partitions and plumbing fixtures. Rear wall toilet grab bars feature twenty-four inch minimum and twelve inch minimum segments relative to the centerline. Patient-sized conditions modify specific dimensional requirements according to the associated plan notations.
TO CL 2' - 10" _ REFER TO PLAN FOR LENGTH AND CONFIGURATION GRAB BAR C 12" E1 18" E2 SIDE WALL TOILET GRAB BAR E5 42" D C AT PATIENT OF SIZE CONDITIONS ONLY MAX 12” 54" MIN TYP TO CL 2' - 10" TYP TO CL 2' - 10" TYP TO CL 2' - 10" MIN 12” MIN 24” REAR WALL TOILET GRAB BAR E4 36" D C AT PATIENT OF SIZE CONDITIONS ONLY FINISH FACE OF WET WALL FINISH FACE OF WET WALL
