This architectural plan detail shows a curved gypsum wallboard soffit layout referencing grid lines B and B.2. The curved geometry is defined by specific radius dimensions including a 3'-0" radius arc and tangent points. Lightweight concrete fill LWC-1 and gypsum wallboard GWB soffit framing are indicated with linear dimensions.
B B.2 R 3 ' - 0 " 2 ' - 5 1 / 4 " 2 ' - 4 1 / 2 " 1 ' - 8 1 / 8 " 6 3 / 8 " 1 ' - 2 1 / 8 " 1 4 ' - 0 1 / 8 " 1 3 / 4 " 1 / 8 " R 2 ' - 6 " LWC-1 SFCS-1 T A N G E N T P O I N T S T A N G E N T P O I N T S G W B S O F F I T
