The partition runner track is secured to the ceiling main beam or cross tees with number 10 sheet metal screws at four feet on center at a square edge lay-in ceiling. The lay-in ceiling system runs continuous over the partition with acoustic insulation installed above as required by reflected ceiling plans. The partition type is indicated on the floor plans and includes acoustical insulation where scheduled.
LAY-IN CEILING SYSTEM SHALL RUN CONTINUOUS OVER PARTITION ACOUSTIC INSULATION AS REQUIRED BY REFLECTED CEILING PLANS CEILING SYSTEM MAIN BEAM PARTITION TYPE AS INDICATED ON THE FLOOR PLANS ACOUSTICAL INSULATION WHERE SCHEDULED SECURE PARTITION RUNNER TRACK TO CEILING MAIN BEAM OR CROSS TEES WITH #10 SHEET METAL SCREWS AT 4'-0" OC AT SQUARE EDGE LAY-IN CEILING A
