An exterior patio assembly consists of single-ply roofing over rigid insulation supported by a concrete-filled metal deck roof on a steel beam. A concrete curb separates the patio from the interior floor slab, which is constructed of concrete over compressed rigid insulation. The patio roof slopes away from the wall structure.
PATIO 56'-0" SINGLE PLY ROOFING OVER RIGID INSULATION CONCRETE OVER METAL DECK ROOF STEEL BEAM CONCRETE OVER COMPRESSED RIGID INSULATION FLOOR CONCRETE CURB
