An exterior wall movement joint assembly features steel studs with batt insulation, glass mat sheathing, a fluid-applied water-resistive barrier, and one and one-half inches of continuous rigid insulation beneath a composite stone panel system. The movement joint is sealed with a pre-formed ultra-low-modulus silicone rubber extrusion with silicone seal bonded to the water-resistive barrier and backed with mineral wool packing. Overall dimensions and finish face clearances are dimensioned relative to the structural grid line.
B TYP UNO - REF PLANS 2' - 3" TO FINISH FACE 2' - 3" 2' - 3" 1' - 0 1/2" 10" 1' - 2 1/2" 1' - 0 1/2" PLANS SEE COMPOSITE STONE PANEL SYSTEM BUILDING WRAP 1 1/2" CONT RIGID INSULATION FLUID APPLIED WRB GLASS MAT SHEATHING STEEL STUD W/ BATT INSULATION AT MOVEMENT JOINT; PRE-FORMED ULTRA LOW MODULUS SILICONE RUBBER EXTRUSION W/ SILICON SEAL TO WRB; FILL JOINT W/ MINERAL WOOL 3"
