Head condition of a non-load-bearing hollow metal window frame integrated with metal stud framing and glazing. The hollow metal frame surrounds the partition head, anchored adjacent to the ceiling where it occurs per the reflected ceiling plan. Glazing is secured within the frame using glass stops located as shown, with specific dimensional clearances of 5/8 inch, 3/8 inch, and 3/16 inch plus glass thickness.
5/8" 3/8" 5/8" 5/8" 3/16" + GLASS THICKNESS GLASS STOPS LOCATION AS SHOWN GLAZING REFER TO PLANS MET STUD-1 CEILING WHERE OCCURS, SEE RCP. HOLLOW METAL WINDOW FRAME REFER TO PLANS 3" = 1'-0" 15 HOLLOW METAL WINDOW FRAME DETAILS - HEAD NON LOAD-BEARING
