An ADA compliant shower room sign featuring raised pictograms, raised text, and grade II braille is mounted with 3M series 4032 VHB foam tape. The overall panel dimensions measure nine inches in height by seven inches in width. Specific vertical spacing and layout dimensions are called out for the text fields and graphic elements.
SHOWER GRADE 2 BRAILLE 3/4" 1/2" 3/4" 1/2" 1/4" 1/2" 2 3/4" 3" TYPE D 1 1/4" 3 3/4" 9" 7" GRADE II BRAILLE MOUNTED WITH 3M SERIES 4032 VHB FOAM TAPE ADA PANEL WITH RAISED TEXT GRADE II BRAILLE MOUNTED WITH 3M SERIES 4032 VHB FOAM TAPE RAISED TEXT AS SHOWN
