A rated fire extinguisher cabinet is installed within a minimum six-inch metal stud or chase partition construction to satisfy one- or two-hour partition requirements with forty-five, sixty, or ninety-minute opening requirements. Acoustical insulation is included where required per the specific partition type. A two-and-one-half-inch dimension governs the projection and clearance of the cabinet assembly.
ACOUSTICAL INSULATION WHERE REQUIRED PER PARTITION TYPE PARTITION, SEE PLANS FOR TYPES NOTE: MINIMUM 6" METAL STUD OR CHASE PARTITION CONSTRUCTION REQUIRED TO FIT RATED FIRE EXTINGUISHER CABINET AT 1 OR 2 HOUR PARTITION WITH 45, 60 OR 90 MINUTE OPENING REQUIREMENT 2 1/2"
