An exterior concrete wall panel supports a coiling overhead door and a rapid fabric door at the loading dock. A four-foot-high track guard, provided by the dock equipment subcontractor and painted safety yellow, is secured to the concrete wall. Steel door guides are welded to bent plates which are anchored back to the concrete wall panel. The coiling overhead door operates within the steel door guide assembly, while the rapid fabric door and housing are installed per manufacturer instructions.
