This platform edge detail features a wood-framed platform supported by a composite steel and concrete floor deck with an expanded polystyrene filler between walls. The platform surface is finished with carpeting specified per finish plans, featuring a Roppe #11 rubber nosing with seventy percent minimum contrast to the carpet color. A two-inch by four-inch wood cleat provides framing support at the edge assembly. Carpeting returns down the vertical face of the platform as indicated.
1/2" SEE PLANS CARPETING, SEE FINISH PLANS FOR TYPE RUBBER NOSING, ROPPE #11, 70% MIN. CONTRAST TO CARPET COLOR SEE 5/S6.01 CARPETING, SEE FINISH PLANS FOR TYPE COMPOSITE STEEL AND CONCRETE FLOOR DECK, S.S.D. 2X CLEAT EPS FILLER BETWEEN WALLS, S.S.D.
