Continuous Backing Track at PVC Wall Panel Transition

Materials

Elements

About this detail

Interior wall assembly featuring white and gray PVC wall panels installed over a continuous 20 gauge by 6-inch wide metal backing track. A continuous vapor retarder is positioned behind the backing track and panels. The transition between the white and gray panels is centered on the backing track at 5 feet above finished floor.
