Zinc wall cladding panels meet at an exterior concrete wall corner, incorporating folded panel edges and continuous corner trim profiles. The panels are secured over the backup wall assembly with concealed fasteners and fastening clips. Joint details provide weather protection and accommodate thermal movement at the exterior corner.
