An automatic door bottom sits within the bottom of a scheduled door held inside an as-cast formed concrete door frame. A threshold plate spans the opening, bearing down on a carpet tile walkoff mat on one side and resilient tile flooring on the other. A transition strip matches the adjacent wall base finish at the junction with the carpet tile. The entire assembly bears on an as-cast formed concrete slab.
AS-CAST FORMED CONCRETE DOOR FRAME SCHEDULED DOOR CARPET TILE/WALKOFF MAT, REFER TO FINISH PLAN RESILIENT TILE FLOORING TRANSITION STRIP TO MATCH ADJ WALL BASE FINISH THRESHOLD AUTOMATIC DOOR BOTTOM AS-CAST FORMED CONCRETE DOOR FRAME SCHEDULED DOOR CARPET TILE/WALKOFF MAT, REFER TO FINISH PLAN RESILIENT TILE FLOORING TRANSITION STRIP TO MATCH ADJ WALL BASE FINISH THRESHOLD AUTOMATIC DOOR BOTTOM
