A continuous one-eighth-inch painted aluminum trim interfaces with a metal panel MP1 system head secured to a concrete masonry unit wall via a clip anchor and shims as needed. Structural blocking sits within the joint space, sealed with sealant and backer rod colored to match adjacent mortar typically. The concrete masonry unit wall incorporates bond beams and reinforcing sized per structural engineering requirements.
1/2" 1/2" 1" SECTION DIM SECTION DIM PLAN DIM WA13 WA6 CMU BOND BEAM AND REINFORCEMENT PER STRUCTURAL SEALANT AND BACKER ROD, COLOR TO MATCH ADJACENT MORTAR, TYP CONT 1/8" PTD ALUM TRIM, COLOR TO MATCH METAL PANEL MP1 SYSTEM CLIP ANCHOR TO CMU, SHIM AS NEEDED STRUCTURAL BLOCKING 7 5/8" 2" 3/16"
