A-8XRHJ — Window - Head at Typ Branch Storefront

Architectural · A-8XRHJ

Window - Head at Typ Branch Storefront

Units: imperial
Sheet: A7.51
Discipline: Architectural

Materials

Aluminum Composite Glass / Glazing Timber / Wood

Elements

Ceilings Expansion / Control Joints Insulation Storefronts Waterproofing / Flashing Windows

Text on the drawing

CEILING PER DRIFT JOINT STRUCTURAL STOREFRONT WITH COMP. HEAD BACKER ROD AND SEALANT. SET SEALANT BACK FROM FACE 3/8" MIN. (HIDDEN FROM VIEW) 3/4" T&G SOFFIT. BUTT TO BLOCK BLIND NAIL. TYP. 3/4" PLYWOOD SHEATHING 3/4" BLOCK FRAMING PER STRUCTURAL R3 R3 FOAMED IN PLACE INSULATION. FILL CAVITY 6" DEEP
