This plan detail shows a curtain wall vertical mullion connected to adjacent aluminum panels with firestopping. An angle is attached to the mullion alongside impaling pins, with sealant and backer rod designated as SE-03. Firestop details are referenced to sheet INS-01B and SE-03.
L C IMPALING PIN, SEE FIRESTOP DETAILS INS-01B CURTAIN WALL VERTICAL MULLION ANGLE ATTACHED TO MULLION, SEE FIRESTOP DETAILS SE-03 AND BACKER ROD SEE FIRESTOP DETAIL SEE FIRESTOP DETAIL INS-01B ALUM PANEL 3"
