A-8WSEM — Elevator Shaft at Roof

Architectural · A-8WSEM

Elevator Shaft at Roof

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Metal (misc.)Steel

Elements

Beams Decks Floors / Slabs Roof / Floor Openings Roofs Walls

Text on the drawing

6 FIRE CAULK STRUCTURAL BEAM, RE: STRUCTURAL DRAWINGS INTERIOR WALL ASSEMBLY; SEE FLOOR PLANS METAL DECKING, RE: STRUCTURAL DRAWINGS 5
